SIRIS 4 / NAS 4 X Enterprise features and specifications

Topic

This article provides the layout, hardware specifications, and features for Datto's SIRIS 4 / Datto NAS 4 X Enterprise devices.

Environment

  • SIRIS 4 / Datto NAS 4 X Enterprise

Description

Device Layout

Figure 1: SIRIS 4 / Datto NAS 4 X Enterprise, front view

Figure 2: SIRIS 4 / Datto NAS 4 X Enterprise, rear view

  1. Power button
  2. Unit identification LED
  3. System reset
  4. USB 3.0
  5. Array drive bays
  6. USB 3.0
  7. 2 x hot-swappable power supply
  8. OS drive
  9. Transfer drive
  10. VGA out
  11. Serial port
  12. 2 x 1GbE
  13. 2 x 10GbE
  14. 1 x IPMI
  15. 2 x USB 3.0
  16. UID

LED Behavior

Power LED indicator:

This LED indicator represents the power state of the device:

  • Power on: Solid blue
  • Power off: Dark (the LED is off)

Unit identification LED Indicator

This will glow blue when the unit identification LED is pressed.

Power Supply Unit (PSU) LED Indicator

This LED will display the following behaviors under certain conditions:

  • Output ON and OK: Solid green
  • No AC power to PSU or any PSU in parallel: Dark (the LED is off)
  • AC present/only standby output on: Slow flashing green
  • AC cord unplugged or AC power lost with a second power supply in parallel still with AC input power: Solid amber
  • Abnormal conditions are present on the device, such as high temperatures, high power, high current, or slow spinning fans: Slow blinking amber
  • PSU critical event causing shutdown, such as over-current, over-voltage, or fan failure: Fast blinking amber
  • PSU firmware update mode: Fast blinking green

HDD LED Indicator

Each bay contains a pair of LED lights that display the following behaviors under certain conditions:

Power LED

  • Hard drive fault has occurred: Dark (the LED is off)
  • Powered on and operational: Solid blue

Activity LED

  • HDD is busy and operational: Solid green
  • Drive is booting and spinning up: Blinking red

Features

Hardware Specifications

SIRIS 4 / Datto NAS 4 X Enterprise 18

Model S4-XE18 / DN-4XE18
Weight 39.5 lb
Dimensions 26" L (29.88" with ears)
17.6" W (19" with ears)
3.5" H
Capacity 18 TB (Flash)
CPU (2x) Intel Xeon Silver 4214
RAM 64 GB (DDR4)
Array RAID 6
NICs 2 x 10GbE + 2x1GbE
Dedicated OS Drive 240 GB SSD
Form Factor 2U
Agent-level encryption Supported on SIRIS

SIRIS 4 / Datto NAS 4 X Enterprise 36

Model S4-XE36 / DN-4XE36
Weight 39.5 lb
Dimensions 26" L (29.88" with ears)
17.6" W (19" with ears)
3.5" H
Capacity 36 TB (Flash)
CPU 2 x Intel Xeon Gold 5218
RAM 120 GB (DDR4)
Array RAID 6
NICs 2 x 10GbE + 2x1GbE
Dedicated OS Drive 240 GB SSD
Form Factor 2U
Agent-level encryption Supported on SIRIS

SIRIS 4 / Datto NAS 4 X Enterprise 48

Model S4-XE48 / DN-3XE48
Weight 39.5 lb
Dimensions 26" L (29.88" with ears)
17.6" W (19" with ears)
3.5" H
Capacity 48 TB (Flash)
CPU 2 x Intel Xeon Gold 6240
RAM 256 GB (DDR4)
Array RAID 6
NICs 2 x 10GbE + 2x1GbE
Dedicated OS Drive 240 GB SSD
Form Factor 2U
Agent-level encryption Supported on SIRIS
