[LEGACY] SIRIS 3 X Professional Features & Specifications
Topic
This article provides the layout, hardware specifications, and features for Datto's SIRIS 3 / Datto NAS 3 X Professional devices.
Environment
- SIRIS 3 / Datto NAS 3 X 4 Professional
- SIRIS 3 / Datto NAS 3 X 8 Professional
- SIRIS 3 / Datto NAS 3 X 12 Professional
Device Layout
Figure 1: SIRIS 3 / Datto NAS 3 X Professional, front view (click for larger image)
Figure 2: SIRIS 3 / Datto NAS 3 X Professional, rear view (click for larger image)
- Faceplate release toggles
- Power button
- Unit identification LED
- 2 x USB 3.0
- Array drives
- 2 x hot-swappable power supply
- 2 x USB 3.0
- IPMI
- Serial port
- VGA out
- 2 x 10GbE
LED Behavior
Power LED indicator:
This LED indicator represents the power state of the device:
- Power on: Solid blue
- Power off: Dark (the LED is off)
Unit identification LED Indicator
This will glow blue when the unit identification LED is pressed.
Power Supply Unit (PSU) LED Indicator
This LED will display the following behaviors under certain conditions:
- Output ON and OK: Solid green
- No AC power to PSU or any PSU in parallel: Dark (the LED is off)
- AC present/only standby output on: Slow flashing green
- AC cord unplugged or AC power lost with a second power supply in parallel still with AC input power: Solid amber
- Abnormal conditions are present on the device, such as high temperatures, high power, high current, or slow spinning fans: Slow blinking amber
- PSU critical event causing shutdown, such as over-current, over-voltage, or fan failure: Fast blinking amber
- PSU firmware update mode: Fast blinking green
HDD LED Indicator
Each bay contains a pair of LED lights that display the following behaviors under certain conditions:
Power LED
- Hard drive fault has occurred: Dark (the LED is off)
- Powered on and operational: Solid blue
Activity LED
- HDD is busy and operational: Solid green
- Drive is booting and spinning up: Blinking red
Features
Hardware Specifications
SIRIS 3 / Datto NAS 3 X 4 Professional
| Model | S3XP4 / DN-3XP4 |
| Weight | 19.5 lb |
| Dimensions | 21.75" L (22.63" with ears) 17.25" W (19" with ears) 1.75" H |
| Capacity | 4 TB (Flash) |
| CPU | Xeon D 1541 |
| RAM | 48 GB (DDR4) |
| Array | RAID 5 |
| NICs | 2 x 10GbE |
| Dedicated OS Drive | 240 GB SSD |
| Form Factor | 1U 10-bay, 2.5" hot-swappable |
| Encryption | Supported |
SIRIS 3 / Datto NAS 3 X 8 Professional
| Model | S3XP8 / DN-3XP8 |
| Weight | 19.5 lb |
| Dimensions | 21.75" L (22.63" with ears) 17.25" W (19" with ears) 1.75" H |
| Capacity | 8 TB (Flash) |
| CPU | Xeon D 1541 |
| RAM | 48 GB (DDR4) |
| Array | RAID 5 |
| NICs | 2 x 10GbE |
| Dedicated OS Drive | 240 GB SSD |
| Form Factor | 1U 10-bay, 2.5" hot-swappable |
| Encryption | Supported |
SIRIS 3 / Datto NAS 3 X 12 Professional
| Model | S3XP12 / DN-3XP12 |
| Weight | 19.5 lb |
| Dimensions | 21.75" L (22.63" with ears) 17.25" W (19" with ears) 1.75" H |
| Capacity | 12 TB (Flash) |
| CPU | Xeon D 1541 |
| RAM | 64 GB (DDR4) |
| Array | RAID 5 |
| NICs | 2 x 10GbE |
| Dedicated OS Drive | 240 GB SSD |
| Form Factor | 1U 10-bay, 2.5" hot-swappable |
| Encryption | Supported |
